ZOLLER Inc. President Alexander Zoller highlights new tool heat shrink technology and more while Matt Brothers, Industry 4.0 Tech Center manager, describes a new measuring program for presetting skiving cutters.

ANCA USA General Manager Russell Riddiford visits with various ANCA experts during IMTS 2022 to discuss several of the machines on display, including the new ANCA Integrated Manufacturing System (AIMS).

Made for large, heavy parts with complex dimensions and tolerances, FlexPoint 12-Series measures volumes up to 1200 x 3000 x 1000 mm. The VersaFlex multisensor head is a patented sensor array that offers up to three simultaneously available sensors on one articulating head: OGP SmartProbe fully telecentric optical video probe, SP25 scanning probe, and the interferometric laser TeleStar Probe.

TurnCheck systems are precision optical instruments that measure shafts, cylinders, and other turned, ground, or extruded parts in the most demanding shop floor environments. The fully telecentric large field of view optics combined with highly collimated light at a constant wavelength results in a crisp, uniformly magnified image with no edge effects or exclusion zones.

OGP has reimagined the trusted SmartScope system to be accessible for all skill levels and budgets. SmartScope E7 features the brand-new fixed lens IntelliCentric optical system, a fully telecentric optical system that provides a super high-resolution image perfect for video edge detection.

ShapeGrabber 3D Laser Scanning systems are metrology-class machines that combine powerful laser and camera technology to capture up to 1.5 million data points per second. At the heart of each ShapeGrabber system is a high-resolution scanhead offering dynamic range that delivers fast and accurate measurement of parts in a wide variety of materials, colors, textures, and finishes.

Users of optical comparators and measuring microscopes and more will find this of particular interest as it meets the need for basic 2D metrology functions. The Q functions as an entry-level readout, providing the user with geometric feature construction, basic part view detail and data output via USB-C connection.

The Digimar 817 CLT provides a variety of interfaces for saving measurement data. Data transfer is possible both wirelessly and by the new duplex cable via the proven MarConnect data management software. It also allows the transmission of a measuring device ID to ensure the traceability of all measurement results.

With practical touch control panels, the new digital comparators offer maximum measuring reliability even in harsh workshop environments. A light tap on the touchscreen is sufficient to safely operate the digital comparators with most commercially available gloves. This eliminates the possibility of measurement errors by accidental adjustment or deformation of the comparator.

The wireless RCD from Kistler has a 10 kHz sampling rate that allows to capture highly dynamic foot-prints of the measurement in applications with up to 16 000 RPM. Overall, piezoelectric sensors ensure more accurate measurements than other technologies, such as strain-gauge sensors, which have significant limitations especially when measuring small forces and high dynamic processes.

The unit control of the Connect.series range, with its compact size, has a large 10'' touch screen in tempered glass and pairs in just a few seconds to the marking head thanks to the RFID technology. It can connect to the network and exchange data with the information system (ERP, MES).

The blue laser, paired with an intelligent measuring system, provides high-precision measurement of various tool parameters on cylindrical tools with diameters from one to 52 mm. Since it does not contact the surface, the Laser Contour Check avoids possible damage to cutting edges or measuring errors that can occur due to wear on the probe tip during tactile measurements.
