Boasting a real 15 W of optical power as well as a novel design, this is the first compact CNC laser head that not only marks metal, but deep-engraves it. Utilizing blue laser light, it can efficiently process materials that infrared lasers struggle with. Furthermore, it can be adapted to nearly any CNC machine.

A major highlight in the new HALCON 21.05 version is the Generic Shape Matching feature, which makes MVTec's industry-proven shape matching technologies even more user-friendly and future proof. Users can now implement their solutions much faster and more easily, thanks to a significant reduction in the number of operators required. Moreover, thanks to the unification of HALCON's different shape matching methods into a single set of operators, users can now integrate new shape-matching-related features more easily.

The speed and precision of the OptoFlash enables 100+ static measurements on parts up to 60mm in length and 20 mm in diameter within two seconds at U95 = 1 µm + D/200 (D in mm) with the ability to switch from one-part type to another with just one click (flexible gauge). It captures images of the component over the 360° degrees, automatically combining several images to determine both part optical axis and measurements of the features.n

PJ-Plus is a series of profile projectors that utilize LED lighting and provides reliable measurements in manufacturing site environments. The PJ-Plus provides stable dimension and angle measurements in harsher environments conventional models can't handle, such as manufacturing and processing lines.n

Merlin Plus software offers multiple measurement and statistical displays with numeric and graphic layout, trend limits, data traceability, batch management, part counters, and data storage; exporting in CSV or Q-DAS format. It can handle up to 250 different measurements, 1,000 different part programs and offers connection to several type of devices with built-in drivers.

In developing a measurement and feedback process, for each parameter/feature listed, ANCA and ZOLLER have worked together to agree upon a fixed ZOLLER measurement process and a fixed ANCA grinding parameter adjustment to which it is directly linked. Wheel adjustments are not supported as an option for this method of compensation. Adjustments are applied to parameters for compensation without changing the design parameters.

The Runtime Module allows trained AI module to be incorporated into an inspection system. Included in the Runtime module model is the inference testing application that allows review of the AI model for sample testing on new images.

Operation has been greatly simplified and efficiency doubled, enhancing the system's suitability for a wide range of applications from the museum laboratory through academia to the R&D department and on to the factory floor. The intrinsic benefit of X-ray CT is that it allows both the exterior and interior of a sample to be inspected and measured non-destructively. The XT H 225 ST 2x, which has undergone thousands of hours of rigorous testing, is distinguished by its ability to be tuned to match the part under investigation so that optimal results are produced every time.

The new user-friendly software is designed with an intuitive interface that allows anyone to use and configure new measurements on an Optoquick or Optoflash system, helping build even more efficiency into the process. All measurements are archived for retrieval by the smart search function.n

In terms of speed, all machines now accelerate at 1,900 mm/s2, representing an increase of 15% for the two smaller models and 20% for the largest model. Velocity is up by 38% across the product range to 720 mm/s. As regards accuracy, maximum permissible measuring error on all machines is now 1.7+L/333 µm when measurements are taken of a feature L millimeters in length between 18°C and 22°C, irrespective of whether a TP200, SP25, TP20 or PH20 probe is used. This performance represents length measurement accuracy improvements of 22%, 22%, 32% and 43% for the four respective probes, while maximum permissible probing error is also better and so also is repeatability of measurements by 15% when using a PH20.

Called FREEDOM ULTIMATE and FREEDOM ULTIMATE SCAN, the new arms are available with measurement volumes from 2.5 to 4.5 metres, according to model. Each complements the comparable size of existing FREEDOM CLASSIC and higher accuracy FREEDOM SELECT products with six axes designed for touch probing, as well as the 7-axis SCAN equivalents for multi-sensor metrology including laser scanning.

Designed for robustness, reliability, affordability and ease of use, Deltron, is a shop floor hardened non-Cartesian CMM with an innovative delta robotic mechanism, reknown for repeatable motion, fast acceleration and a high level of measurement accuracy. The delta mechanism on Deltron operates with a maximum vector speed of 500mm/sec and a maximum vector acceleration of 750mm/sec2.
